Please contact us for more photos of MM3Z22VC
| Part Number | MM3Z22VC |
|---|---|
| Manufacturer | Fairchild Semiconductor |
| Quantity in stock | 644270 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode Zener Single 22V 5% 200mW 2-Pin SOD-323F T R |
| Category | Discrete Semiconductor |
| Family | Diode |
| ROHS Compliant | Yes |
| MSL Level | MM3Z22VC |
| Datasheet download |  MM3Z22VC.pdf |
| Part Number | MM3Z22VC |
|---|---|
| Product Dimensions | 1.7 x 1.3 x 1 mm |
| Operating Temperature | -65 to 150 °C |
| Test Current | 5 mA |
| Maximum Zener Impedance | 51 Ohm |
| Pin Count | 2 |
| Maximum Power Dissipation | 200 mW |
| Rad Hard | No |
| Configuration | Single |
| Max Processing Temp | 260 |
| Nominal Zener Voltage | 22 V |
| Lead Finish | Matte Tin |
| Zener Voltage Tolerance | 5 % |
| Mounting | Surface Mount |
| ESD Protection | No |
| Supplier Package | SOD-323F |
| MSL Level | 1 |
| Maximum Reverse Leakage Current | 0.045 uA |
| Package | 2SOD-323F |
| Replacement Part Number | PART-MM3Z22VC |
| Weight | Contact us |
| Country of Origin | - |
