Please contact us for more photos of 37203-1BE0-003PL
| Part Number | 37203-1BE0-003PL |
|---|---|
| Manufacturer | 3M |
| Quantity in stock | 392890 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Wire to Board SKT 3 POS 2mm Solder RA SMD T R |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 37203-1BE0-003PL |
| Datasheet download |  37203-1BE0-003PL.pdf |
| Part Number | 37203-1BE0-003PL |
|---|---|
| Operating Temperature | -20 to 60 °C |
| Housing Color | Black |
| Termination Method | Solder |
| Mounting | Surface Mount |
| Pitch | 2 mm |
| Maximum Voltage Rating | 32 V |
| Number of Contacts | |
| MSL Level | 1 |
| Body Orientation | Right Angle |
| Pin Count | 3 |
| Number of Rows | |
| Maximum Contact Resistance | |
| Housing Material | Liquid Crystal Polymer |
| Lead Finish | Gold Flash Over Nickel |
| Product Dimensions | 13.8 x 14.05 x 7.7 |
| Contact Plating | Gold Over Nickel |
| Gender | SKT |
| Max Processing Temp | 260 |
| Maximum Current Rating | 3 A |
| Type | Wire to Board |
| Contact Material | Copper Alloy |
| Rad Hard | No |
| Product Depth | 14.05 mm |
| Product Height | 7.7 mm |
| Product Length | 13.8 mm |
| Replacement Part Number | PART-37203-1BE0-003PL |
| Weight | Contact us |
| Country of Origin | - |
