Please contact us for more photos of 10120666-101LF
| Part Number | 10120666-101LF |
|---|---|
| Manufacturer | Amphenol-FCI |
| Quantity in stock | 221990 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn MINI-SAS RCP 36 POS 0.75mm Press Fit ST Thru-Hole 36 Terminal 1 Port |
| Category | Connectors |
| Family | Connector SCSI |
| ROHS Compliant | Yes |
| MSL Level | 10120666-101LF |
| Datasheet download |  10120666-101LF.pdf |
| Part Number | 10120666-101LF |
|---|---|
| Product Dimensions | 15.46 x 16.7 x 13.83 |
| Body Orientation | Straight |
| Housing Material | Thermoplastic |
| Gender | RCP |
| Number of Terminals | 36 |
| Termination Method | Press Fit |
| Number of Contacts | 36 |
| Pitch | 0.75 mm |
| Contact Plating | Gold Over Nickel |
| Type | MINI-SAS |
| Contact Material | Copper Alloy |
| Number of Ports | 1 |
| Pin Count | 36 |
| Lead Finish | Tin Over Nickel |
| Mounting | Through Hole |
| Rad Hard | No |
| Operating Temperature | -40 to 80 °C |
| Product Depth | 16.7 mm |
| Product Height | 13.83 mm |
| Product Length | 15.46 mm |
| Replacement Part Number | PART-10120666-101LF |
| Weight | Contact us |
| Country of Origin | - |
