Please contact us for more photos of 59112-G3610-100LF
| Part Number | 59112-G3610-100LF |
|---|---|
| Manufacturer | Amphenol-FCI |
| Quantity in stock | 428210 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Board Stacker HDR 20 POS 2mm Solder ST Thru-Hole Bag |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 59112-G3610-100LF |
| Datasheet download |  59112-G3610-100LF.pdf |
| Part Number | 59112-G3610-100LF |
|---|---|
| Housing Material | Thermoplastic |
| Contact Material | Copper Alloy |
| Mounting | Through Hole |
| Max Processing Temp | 255|260 |
| Pitch | 2 mm |
| Rad Hard | No |
| Body Orientation | Straight |
| Termination Method | Solder |
| Housing Color | Black |
| Lead Finish | Gold |
| Product Dimensions | 20 x 4 x 14.6 mm |
| Contact Plating | Gold |
| Gender | HDR |
| Product Depth | 4 mm |
| Product Height | 14.6 mm |
| Product Length | 20 mm |
| Replacement Part Number | PART-59112-G3610-100LF |
| Weight | Contact us |
| Country of Origin | - |
