Please contact us for more photos of 69154-207LF
| Part Number | 69154-207LF |
|---|---|
| Manufacturer | Amphenol-FCI |
| Quantity in stock | 542540 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Socket Strip SKT 14 POS 2.54mm Solder ST SMD Tube |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 69154-207LF |
| Datasheet download |  69154-207LF.pdf |
| Part Number | 69154-207LF |
|---|---|
| Mounting | Surface Mount |
| Maximum Contact Resistance | 15 mOhm |
| Termination Method | Solder |
| Housing Color | Black |
| Lead Finish | Tin |
| Body Orientation | Straight |
| Operating Temperature | -65 to 125 °C |
| Maximum Voltage Rating | 1000 Vac |
| Housing Material | Polyphenylene Sulfide |
| Maximum Current Rating | 3/Contact A |
| Pitch | 2.54 mm |
| Type | Socket Strip |
| Contact Plating | Gold Over Nickel |
| Max Processing Temp | 260 |
| Number of Rows | 2 |
| Gender | SKT |
| Contact Material | Phosphor Bronze |
| Rad Hard | No |
| Product Dimensions | 23.29 x 5.08 x 7.87 mm |
| Product Depth | 5.08 mm |
| Product Height | 7.87 mm |
| Product Length | 23.29 mm |
| Replacement Part Number | PART-69154-207LF |
| Weight | Contact us |
| Country of Origin | - |
