Please contact us for more photos of 71918-240LF
| Part Number | 71918-240LF |
|---|---|
| Manufacturer | Amphenol-FCI |
| Quantity in stock | 369230 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Ejector Header HDR 40 POS 2.54mm Solder ST Thru-Hole Tube |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | 71918-240LF |
| Datasheet download |  71918-240LF.pdf |
| Part Number | 71918-240LF |
|---|---|
| Number of Contacts | |
| Maximum Current Rating | |
| Maximum Voltage Rating | |
| Maximum Contact Resistance | |
| Type | |
| Number of Rows | |
| Rad Hard | No |
| Housing Color | Gray |
| Contact Plating | Gold Over Nickel/GXT Over Nickel |
| Pitch | 2.54 mm |
| Housing Material | Thermoplastic |
| Contact Material | Phosphor Bronze |
| Max Processing Temp | 260 |
| Termination Method | Solder |
| Lead Finish | Matte Tin |
| Body Orientation | Straight |
| Mounting | Through Hole |
| Operating Temperature | -65 to 125 °C |
| Product Dimensions | 70.1 x 8.6 x 24 mm |
| Gender | HDR |
| Product Depth | 8.6 mm |
| Product Height | 24 mm |
| Product Length | 70.1 mm |
| Replacement Part Number | PART-71918-240LF |
| Weight | Contact us |
| Country of Origin | - |
