Please contact us for more photos of 951400J30H
| Part Number | 951400J30H |
|---|---|
| Manufacturer | Amphenol |
| Quantity in stock | 887500 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Backplane HDR 32Signal 32Ground POS 1.85mm Press Fit ST Thru-Hole |
| Category | Connectors |
| Family | Connector Backplane |
| ROHS Compliant | Yes |
| MSL Level | 951400J30H |
| Datasheet download |  951400J30H.pdf |
| Part Number | 951400J30H |
|---|---|
| Contact Material | Copper Alloy |
| Lead Finish | Gold Over Nickel |
| Type | Backplane |
| Contact Plating | Gold Over Nickel |
| Rad Hard | No |
| Housing Color | Gray |
| Number of Contacts | 32Signal/32Ground |
| Package Dimensions | 24.76 x 7.35 x 13.4 mm |
| Housing Material | Liquid Crystal Polymer |
| Maximum Contact Resistance | 10 MOhm |
| Termination Method | Press Fit |
| Maximum Current Rating | 1/Contact A |
| Pin Count | 64 |
| Number of Rows | 16 |
| Gender | HDR |
| Body Orientation | Straight |
| Operating Temperature | -40 to 105 °C |
| Mounting | Through Hole |
| Pitch | 1.85 mm |
| Maximum Voltage Rating | 200 Vac |
| Product Depth | 7.35 mm |
| Product Height | 13.4 mm |
| Product Length | 24.76 mm |
| Replacement Part Number | PART-951400J30H |
| Weight | Contact us |
| Country of Origin | - |
