Please contact us for more photos of 1782-11J
| Part Number | 1782-11J |
|---|---|
| Manufacturer | API Delevan |
| Quantity in stock | 323640 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind RF Molded Unshielded 430nH 5% 25MHz 30Q-Factor Phenolic 650mA AXL T R |
| Category | Inductor |
| Family | Inductor Leaded |
| ROHS Compliant | Yes |
| MSL Level | 1782-11J |
| Datasheet download |  1782-11J.pdf |
| Part Number | 1782-11J |
|---|---|
| Lead Style | Axial |
| Package/Case | 2.66 X 6.6 |
| Test Frequency | 25 MHz |
| Product Dimensions | 6.6 mm |
| Lead Finish | Tin/Lead |
| MSL Level | 1 |
| Protection Style | Molded/Unshielded |
| Operating Temperature | -55 to 125 °C |
| Maximum DC Resistance | 350 mOhm |
| Inductance | 430 nH |
| Core Material | Phenolic |
| Type | RF |
| Maximum DC Current | 650 mA |
| Rad Hard | No |
| Minimum Quality Factor | 30@25MHz |
| Maximum Self Resonant Frequency | 330 MHz |
| Tolerance | 5 % |
| Product Diameter | 2.66 mm |
| Product Length | 6.6 mm |
| Replacement Part Number | PART-1782-11J |
| Weight | Contact us |
| Country of Origin | - |
