Please contact us for more photos of 009155002541008
| Part Number | 009155002541008 |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 795750 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Conn Battery M 2 POS 2.5mm Solder RA SMD 2 Terminal 1 Port T R |
| Category | Connectors |
| Family | Connector Power |
| ROHS Compliant | Yes |
| MSL Level | 009155002541008 |
| Datasheet download |  009155002541008.pdf |
| Part Number | 009155002541008 |
|---|---|
| Contact Material | Beryllium Copper |
| Number of Contacts | 2 |
| Pitch | 2.5 mm |
| Number of Ports | 1 |
| Contact Plating | Gold Over Nickel |
| Number of Terminals | 2 |
| Pin Count | 2 |
| Type | Battery |
| Gender | M |
| Body Orientation | Right Angle |
| Rad Hard | No |
| Mounting | Surface Mount |
| Termination Method | Solder |
| Housing Material | Nylon 46 |
| Package Dimensions | 6.5 x 4 x 3.8 mm |
| Operating Temperature | -40 to 125 °C |
| Lead Finish | Gold Over Nickel |
| Product Depth | 4 mm |
| Product Height | 3.8 mm |
| Product Length | 6.5 mm |
| Replacement Part Number | PART-009155002541008 |
| Weight | Contact us |
| Country of Origin | - |
