Please contact us for more photos of 08056D226MAT2A-CV
| Part Number | 08056D226MAT2A-CV |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 857430 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Ceramic 22uF 6.3V X5R 20% SMD 0805 85\u00b0C Emboss T R |
| Category | Capacitors |
| Family | Capacitor Ceramic Multilayer |
| ROHS Compliant | Yes |
| MSL Level | 08056D226MAT2A-CV |
| Datasheet download |  08056D226MAT2A-CV.pdf |
| Part Number | 08056D226MAT2A-CV |
|---|---|
| Package/Case | 0805 |
| Dielectric | X5R |
| Package Dimensions | 2.01 x 1.25 x 1.52 |
| Tolerance | 20 |
| Termination Style | Wraparound |
| Construction | Flat |
| Moisture Sensitivity Level | 1 |
| Case Style | Ceramic Chip |
| Operating Temperature | -55 to 85 °C |
| Pin Count | 2 |
| Lead Finish | Matte Tin Over Nickel |
| Voltage(DC) | 6.3 V |
| Rad Hard | No |
| Mounting | Surface Mount |
| Supplier Package | 0805 |
| Capacitance Value | 22 |
| Maximum Processing Temperature | 260 |
| Case Size | 0805 |
| Product Depth | 1.25 |
| Product Height | 1.52 |
| Product Length | 2.01 |
| Replacement Part Number | PART-08056D226MAT2A-CV |
| Weight | Contact us |
| Country of Origin | - |
