Please contact us for more photos of 12063C104KAT2A
| Part Number | 12063C104KAT2A |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 762430 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Ceramic 0.1uF 25V X7R 10% SMD 1206 125\u00b0C Paper T R |
| Category | Capacitors |
| Family | Capacitor Ceramic Multilayer |
| ROHS Compliant | Yes |
| MSL Level | 12063C104KAT2A |
| Datasheet download |  12063C104KAT2A.pdf |
| Part Number | 12063C104KAT2A |
|---|---|
| Dielectric | X7R |
| MSL Level | 1 |
| Mounting | Surface Mount |
| Lead Finish | Matte Tin |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Case Style | Ceramic Chip |
| Case Size | 1206 |
| Operating Temperature | -55 to 125 °C |
| Construction | Flat |
| Package/Case | 1206 |
| Product Dimensions | 3.2 x 1.6 x 0.94 mm |
| Voltage(DC) | 25 V |
| Capacitance Value | 0.1 uF |
| Tolerance | 10 % |
| Product Depth | 1.6 mm |
| Product Height | 0.94(Max) mm |
| Product Length | 3.2 mm |
| Replacement Part Number | PART-12063C104KAT2A |
| Weight | Contact us |
| Country of Origin | - |
