Please contact us for more photos of 1206GA470JAT1A
| Part Number | 1206GA470JAT1A |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 247560 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Ceramic 47pF 2000V C0G 5% SMD 1206 125\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Ceramic Multilayer |
| ROHS Compliant | Yes |
| MSL Level | 1206GA470JAT1A |
| Datasheet download |  1206GA470JAT1A.pdf |
| Part Number | 1206GA470JAT1A |
|---|---|
| Rad Hard | No |
| Case Size | 1206 |
| Tolerance | 5 % |
| Voltage(DC) | 2 kV |
| Operating Temperature | -55 to 125 °C |
| Package/Case | 1206 |
| Mounting | Surface Mount |
| Max Processing Temp | 260 |
| Dielectric | C0G |
| MSL Level | 1 |
| Lead Finish | Matte Tin |
| Capacitance Value | 47 pF |
| Product Dimensions | 3.2 x 1.6 x 1.52 mm |
| Construction | Flat |
| Case Style | Ceramic Chip |
| Product Depth | 1.6 mm |
| Product Height | 1.52(Max) mm |
| Product Length | 3.2 mm |
| Replacement Part Number | PART-1206GA470JAT1A |
| Weight | Contact us |
| Country of Origin | - |
