709296001004006 AVX

709296001004006 Images

Please contact us for more photos of 709296001004006

Part Number	709296001004006
Manufacturer	AVX
Quantity in stock	306240 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	Contact SKT Solder ST SMD T R
Category	Connectors
Family	Connector Contacts
ROHS Compliant	Yes
MSL Level	709296001004006
Datasheet download	709296001004006.pdf

Request Quotation for 709296001004006

709296001004006 Specifications

Part Number	709296001004006
Wire Size	22 to 26 AWG
Contact Plating	Tin Over Nickel
Contact Size	4
Rad Hard	No
Contact Material	Copper Alloy
Gender	SKT
Operating Temperature	-40 to 125 °C
Termination Method	Solder
Series Name	70-9296
Mounting	Surface Mount
Body Orientation	Straight
Lead Finish	Tin Over Nickel
Product Dimensions	11 x 4 x 4
Shielded	No
Product Depth	4 mm
Product Height	4 mm
Product Length	11 mm
Replacement Part Number	PART-709296001004006
Weight	Contact us
Country of Origin	-
