Please contact us for more photos of CB047G0104JBC
| Part Number | CB047G0104JBC |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 508270 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Film 0.1uF 250V PEN 5% (5.8 X 5 X 4.5mm) SMD 125\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Film |
| ROHS Compliant | Yes |
| MSL Level | CB047G0104JBC |
| Datasheet download |  CB047G0104JBC.pdf |
| Part Number | CB047G0104JBC |
|---|---|
| Voltage(AC) | 160 V |
| Product Dimensions | 5.8 x 5 x 4.5 mm |
| Construction | Flat |
| Voltage(DC) | 250 V |
| Tolerance | 5 % |
| Package/Case | 2220 |
| Lead Finish | Matte Tin |
| Case Size | 2220 |
| Dielectric | PEN |
| Rad Hard | No |
| Mounting | Surface Mount |
| Capacitance Value | 0.1 uF |
| MSL Level | 3 |
| Max Processing Temp | 255 |
| Operating Temperature | -55 to 125 °C |
| Product Depth | 5 mm |
| Product Height | 4.5(Max) mm |
| Product Length | 5.8 mm |
| Replacement Part Number | PART-CB047G0104JBC |
| Weight | Contact us |
| Country of Origin | - |
