Please contact us for more photos of CM03X5R105M06AH
| Part Number | CM03X5R105M06AH |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 493260 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Ceramic 1uF 6.3V X5R 20% SMD 0201 85\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Ceramic Multilayer |
| ROHS Compliant | Yes |
| MSL Level | CM03X5R105M06AH |
| Datasheet download |  CM03X5R105M06AH.pdf |
| Part Number | CM03X5R105M06AH |
|---|---|
| Operating Temperature | -55 to 85 °C |
| Package Dimensions | 0.6 x 0.3 x 0.3 mm |
| Termination Style | Wraparound |
| Tolerance | 20 % |
| Voltage(DC) | 6.3 V |
| Pin Count | 2 |
| Maximum Processing Temperature | 250 °C |
| Package/Case | 0201 |
| Capacitance Value | 1 uF |
| Case Style | Ceramic Chip |
| Construction | Flat |
| Rad Hard | No |
| Lead Finish | Tin Over Nickel |
| Supplier Package | 0201 |
| Mounting | Surface Mount |
| Dielectric | C0G |
| Case Size | 0201 |
| Product Depth | 0.3 mm |
| Product Height | 0.3 mm |
| Product Length | 0.6 mm |
| Replacement Part Number | PART-CM03X5R105M06AH |
| Weight | Contact us |
| Country of Origin | - |
