Please contact us for more photos of SR211C105KARTR2
| Part Number | SR211C105KARTR2 |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 170360 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Ceramic 1uF 100V X7R 10% Radial 5.08mm 125\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Ceramic Multilayer |
| ROHS Compliant | Yes |
| MSL Level | SR211C105KARTR2 |
| Datasheet download |  SR211C105KARTR2.pdf |
| Part Number | SR211C105KARTR2 |
|---|---|
| Dielectric | X7R |
| Voltage(DC) | 100 V |
| Product Dimensions | 5.08 x 3.175 x 5.08 mm |
| Package/Case | 5.08(Max) X 3.175(Max) X 5.08(Max) |
| Seated Plane Height | 7.62 mm |
| Lead Pitch For Radial | 5.08 mm |
| Mounting | Through Hole |
| Termination Style | Radial |
| Case Style | Dipped |
| Rad Hard | No |
| Capacitance Value | 1 uF |
| Tolerance | 10 % |
| Failure Rate | |
| Lead Diameter | 0.508 mm |
| Max Processing Temp | 260 |
| MSL Level | 1 |
| Wire Form | Inside Crimp Standoff |
| Lead Finish | Matte Tin |
| Military Standard | |
| Operating Temperature | -55 to 125 °C |
| Product Depth | 3.175(Max) mm |
| Product Height | 5.08(Max) mm |
| Product Length | 5.08(Max) mm |
| Replacement Part Number | PART-SR211C105KARTR2 |
| Weight | Contact us |
| Country of Origin | - |
