Please contact us for more photos of TLJP476M010R3200
| Part Number | TLJP476M010R3200 |
|---|---|
| Manufacturer | AVX |
| Quantity in stock | 338740 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Tant Solid 47uF 10V P CASE 20% (2.05 X 1.35 X 1.5mm) SMD 2012-15 3.2 Ohm 125\u00b0C T R |
| Category | Capacitors |
| Family | Capacitor Tantalum Solid SMT |
| ROHS Compliant | Yes |
| MSL Level | TLJP476M010R3200 |
| Datasheet download |  TLJP476M010R3200.pdf |
| Part Number | TLJP476M010R3200 |
|---|---|
| Case Size | 2012-15 |
| Product Dimensions | 2.05 x 1.35 x 1.5 mm |
| Package/Case | 2012-15,P |
| Construction | Flat |
| Polarity | Polar |
| Rad Hard | No |
| Case Style | Molded |
| Case Code | P |
| Operating Temperature | -55 to 125 °C |
| Capacitance Value | 47 uF |
| Voltage(DC) | 10 V |
| Equivalent Series Resistance | 3.2 Ohm |
| Leakage Current | 4.7 uA |
| Mounting | Surface Mount |
| Tolerance | 20 % |
| Product Depth | 1.35 mm |
| Product Height | 1.5(Max) mm |
| Product Length | 2.05 mm |
| Replacement Part Number | PART-TLJP476M010R3200 |
| Weight | Contact us |
| Country of Origin | - |
