Please contact us for more photos of 0ZCF0075AF2C
| Part Number | 0ZCF0075AF2C |
|---|---|
| Manufacturer | BEL |
| Quantity in stock | 142230 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | PTC Resettable Fuse 100A 60V T R |
| Category | Circuit Protection |
| Family | PTC Resettable Fuse |
| ROHS Compliant | Yes |
| MSL Level | 0ZCF0075AF2C |
| Datasheet download |  0ZCF0075AF2C.pdf |
| Part Number | 0ZCF0075AF2C |
|---|---|
| Number of Terminals | 2 |
| Operating Temperature | -40 to 85 °C |
| Rad Hard | No |
| Maximum Initial Resistance | 1 Ohm |
| Agency Approvals | TUV|UL |
| Moisture Sensitivity Level | 2A |
| Supplier Package | 2920 |
| Mounting | Surface Mount |
| Typical Power Dissipation | 1.5 W |
| Lead Finish | Matte Tin |
| Maximum Processing Temperature | 260 °C |
| Maximum Voltage Rating | 60 Vdc |
| Trip Current | 1.5 A |
| Package Dimensions | 7.98 x 5.44 x 1.15 mm |
| Package/Case | 2920 |
| Maximum Trip Time | 0.3@8A s |
| Hold Current | 0.75 A |
| Minimum Initial Resistance | 0.18 Ohm |
| Maximum Current Rating | 100 A |
| Product Depth | 5.44(Max) mm |
| Product Height | 1.15(Max) mm |
| Product Length | 7.98(Max) mm |
| Replacement Part Number | PART-0ZCF0075AF2C |
| Weight | Contact us |
| Country of Origin | - |
