Please contact us for more photos of SSQ5A(T&R)
| Part Number | SSQ5A(T&R) |
|---|---|
| Manufacturer | BEL |
| Quantity in stock | 834970 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Fuse Square Body 5A 125V Fast 2-Pin SMD T R |
| Category | Circuit Protection |
| Family | Fuses |
| ROHS Compliant | Yes |
| MSL Level | SSQ5A(T&R) |
| Datasheet download |  SSQ5A(T&R).pdf |
| Part Number | SSQ5A(T&R) |
|---|---|
| Screening Level | Military |
| Voltage Rating | 125 V |
| Acting | Fast |
| Supplier Package | 2410 |
| Maximum Power Dissipation | 0.62 W |
| Rad Hard | No |
| Pin Count | 2 |
| Moisture Sensitivity Level | 1 |
| Lead Finish | Palladium |
| Current Rating | 5 A |
| Maximum AC Voltage Rating | 125 V |
| Package Dimensions | 6.1 x 2.54 x 2.54 mm |
| Fuse Material | Ceramic |
| Mounting | Surface Mount |
| Maximum Processing Temperature | 260 °C |
| Maximum DC Voltage Rating | 125 V |
| Operating Temperature | -55 to 125 °C |
| Type | Square Body |
| Replacement Part Number | PART-SSQ5A(T&R) |
| Weight | Contact us |
| Country of Origin | - |
