Please contact us for more photos of 3262X-1-203LF
| Part Number | 3262X-1-203LF |
|---|---|
| Manufacturer | Bourns |
| Quantity in stock | 436820 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Res Cermet Trimmer 20K Ohm 10% 1 4W 12(Elec)Turn 1.78mm (7.37 X 4.32 X 6.35mm) Pin Thru-Hole Tube |
| Category | Resistor |
| Family | Resistor Trimmers, Potentiometers and Rheostats |
| ROHS Compliant | Yes |
| MSL Level | 3262X-1-203LF |
| Datasheet download |  3262X-1-203LF.pdf |
| Part Number | 3262X-1-203LF |
|---|---|
| Lead Finish | Matte Tin |
| MSL Level | 1 |
| Product Dimensions | 7.37 x 4.32 x 6.35 mm |
| Rad Hard | No |
| Termination Style | Pin |
| Temperature Coefficient | ±100 ppm |
| Shaft Diameter | 1.78 mm |
| Technology | Cermet |
| Operating Temperature | -65 to 150 °C |
| Power Rating | 0.25 W |
| Mounting | Through Hole |
| Resistance Value | 20 kOhm |
| Tolerance | 10 % |
| Max Processing Temp | 260 |
| Product Depth | 4.32 mm |
| Product Height | 6.35 mm |
| Product Length | 7.37 mm |
| Replacement Part Number | PART-3262X-1-203LF |
| Weight | Contact us |
| Country of Origin | - |
