Please contact us for more photos of SMLJ85A
| Part Number | SMLJ85A |
|---|---|
| Manufacturer | Bourns |
| Quantity in stock | 410470 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Diode TVS Single Uni-Dir 85V 3KW 2-Pin DO-214AB |
| Category | Circuit Protection |
| Family | TVS |
| ROHS Compliant | Yes |
| MSL Level | SMLJ85A |
| Datasheet download |  SMLJ85A.pdf |
| Part Number | SMLJ85A |
|---|---|
| Direction Type | Uni-Directional |
| Maximum Peak Pulse Current | 20.8 A |
| Supplier Package | DO-214AB |
| ESD Protection | Yes |
| Maximum Clamping Voltage | 137 V |
| Pin Count | 2 |
| Minimum Breakdown Voltage | 94.4 V |
| Product Dimensions | 7.11 x 6.22 x 2.42 mm |
| Max Processing Temp | 260 |
| Test Current | 1 mA |
| Configuration | Single |
| Maximum Reverse Stand-off Voltage | 85 V |
| Mounting | Surface Mount |
| Operating Temperature | -55 to 150 °C |
| Rad Hard | No |
| MSL Level | 1 |
| Lead Finish | Matte Tin |
| Maximum Reverse Leakage Current | 5 uA |
| Package | 2DO-214AB |
| Replacement Part Number | PART-SMLJ85A |
| Weight | Contact us |
| Country of Origin | - |
