HDSP-F503-JK000 Broadcom

HDSP-F503-JK000 Images

Please contact us for more photos of HDSP-F503-JK000

Part Number HDSP-F503-JK000
Manufacturer Broadcom
Quantity in stock 139660 Pieces
Market Price -
Our Better Price Send by email: [email protected]
Delivery Time 1 day (can ship today)
Description Displays Segmented Module 1DIGIT 8LED Hi-Perf. Green CC 10-Pin DIP Tube
Category Optoelectronics
Family LED Displays
ROHS Compliant Yes
MSL Level HDSP-F503-JK000
Datasheet download HDSP-F503-JK000.pdf
Request Quotation for HDSP-F503-JK000

HDSP-F503-JK000 Specifications

Part Number HDSP-F503-JK000
Product Dimensions 12.9 x 9.79 x 6.36 mm
Pin Count 10
Viewing Area Height 10.16 mm
Viewing Area Length 5.59 mm
Intensity 3500 ucd
Operating Temperature -40 to 100 °C
Supplier Package DIP
Dominant Wavelength 571 nm
Pattern Graphics Segmented
Peak Wavelength 566 nm
Mounting Through Hole
Type Module
Max Processing Temp 250
Maximum Forward Voltage 2.5 V
Lead Finish Tin/Silver/Copper
Maximum Forward Current 30 mA
Total Thickness 6.36 mm
Package 10DIP
Replacement Part Number PART-HDSP-F503-JK000
Weight Contact us
Country of Origin -
