HLMP-1790-A00A2 Broadcom

Please contact us for more photos of HLMP-1790-A00A2

Part Number	HLMP-1790-A00A2
Manufacturer	Broadcom
Quantity in stock	374810 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	LED Uni-Color Green 565nm 2-Pin T-1
Category	Lighting
Family	LEDs
ROHS Compliant	Yes
MSL Level	HLMP-1790-A00A2
Datasheet download	HLMP-1790-A00A2.pdf

Request Quotation for HLMP-1790-A00A2

HLMP-1790-A00A2 Specifications

Part Number	HLMP-1790-A00A2
Max Processing Temp	250
Mounting Orientation	Right Angle
Type	Uni-Color
Maximum Forward Current	7 mA
Maximum Power Dissipation	15.4 mW
Color	Green
Rad Hard	No
LED Material	GaP
Pin Count	2
Product Dimensions	3.43 x 3.43 x 4.7 mm
Mounting	Through Hole
Viewing Angle	50 °
Lead Finish	Matte Tin
Peak Wavelength	565 nm
Supplier Package	T-1
Operating Temperature	-20 to 100 °C
Category	Standard LED
Number of LEDs	1
Lens Appearance	Colored Diffused
Lens Dimensions	3.18x3.18x3.68 mm
Lens Shape Type	Circular
Reverse Voltage	5 V
Maximum Forward Voltage per Color	2.2 V
Intensity	2.3 mcd
Dominant Wavelength	569 nm
Package	2T-1
Replacement Part Number	PART-HLMP-1790-A00A2
Weight	Contact us
Country of Origin	-
