HSMR-C190 Broadcom

Please contact us for more photos of HSMR-C190

Part Number	HSMR-C190
Manufacturer	Broadcom
Quantity in stock	808570 Pieces
Market Price	-
Our Better Price	Send by email: [email protected]
Delivery Time	1 day (can ship today)
Description	LED Uni-Color Blue 469nm 2-Pin Chip LED T R
Category	Lighting
Family	LEDs
ROHS Compliant	Yes
MSL Level	HSMR-C190
Datasheet download	HSMR-C190.pdf

Request Quotation for HSMR-C190

HSMR-C190 Specifications

Part Number	HSMR-C190
Mounting Orientation	Top Mount
Viewing Angle	140 °
Color	Blue
Lead Finish	Gold
Maximum Forward Current	20 mA
Category	Chip LED
Pin Count	2
Reverse Voltage	5 V
Intensity	55 mcd
Type	Uni-Color
Operating Temperature	-30 to 85 °C
Max Processing Temp	255 to 260
LED Material	InGaN
Lens Shape Type	Rectangular
Number of LEDs	1
Lens Dimensions	1x0.8x0.5 mm
Product Dimensions	1.6 x 0.8 x 0.8 mm
MSL Level	2a
Dominant Wavelength	473 nm
Lens Appearance	Colorless Diffused
Mounting	Surface Mount
Supplier Package	Chip LED
Maximum Power Dissipation	78 mW
Maximum Forward Voltage per Color	3.9 V
Peak Wavelength	469 nm
Rad Hard	No
Package	2Chip LED
Replacement Part Number	PART-HSMR-C190
Weight	Contact us
Country of Origin	-
