| Part Number | 74LVC125APW AUJ |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 332080 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Buffer Line Driver 4-CH Non-Inverting 3-ST CMOS 14-Pin TSSOP |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | 74LVC125APW AUJ |
| Datasheet download |  74LVC125APW AUJ.pdf |
| Part Number | 74LVC125APW AUJ |
|---|---|
| Bus Hold | No |
| Number of Outputs per Chip | 4 |
| Mounting | Surface Mount |
| Polarity | Non-Inverting |
| Max Processing Temp | 260 |
| Propagation Delay Test Condition | 50 pF |
| MSL Level | 1 |
| Tolerant I/Os | 5 V |
| Supplier Package | TSSOP |
| Input Signal Type | Single-Ended |
| Screening Level | Extended Industrial |
| Product Dimensions | 5.1(Max) x 4.4 x 0.95(Max) |
| Logic Function | Buffer/Line Driver |
| Number of Channels per Chip | 4 |
| Operating Temperature | -40 to 125 °C |
| Maximum Operating Supply Voltage | 3.6 Vdc |
| Rad Hard | No |
| Maximum Quiescent Current | 40 uA |
| Lead Finish | Gold Over Nickel Palladium |
| Pin Count | 14 |
| Maximum Low Level Output Current | 24 mA |
| Fabrication Technology | CMOS |
| Number of Output Enables per Chip | 0 |
| Typical Operating Supply Voltage | 1.8|2.5|3.3 V |
| Maximum Propagation Delay Time @ Maximum CL | 2.8(Typ)@2.7V|2.5(Typ)@3.3V ns |
| Minimum Operating Supply Voltage | 1.2 Vdc |
| Logic Family | LVC |
| Output Type | 3-State |
| Number of Elements per Chip | 4 |
| Number of Inputs per Chip | 4 |
| Number of Input Enables per Chip | 4 Low |
| Maximum High Level Output Current | -24 mA |
| Package | 14TSSOP |
| Replacement Part Number | PART-74LVC125APW AUJ |
| Weight | Contact us |
| Country of Origin | - |
