Please contact us for more photos of SN74AUC1G125YZPR
| Part Number | SN74AUC1G125YZPR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 188750 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Buffer Line Driver 1-CH Non-Inverting 3-ST CMOS 5-Pin DSBGA T R |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | SN74AUC1G125YZPR |
| Datasheet download |  SN74AUC1G125YZPR.pdf |
| Part Number | SN74AUC1G125YZPR |
|---|---|
| Product Dimensions | 1.4 x 0.9 x 0.3 mm |
| Operating Temperature | -40 to 85 °C |
| Screening Level | Commercial |
| Number of Outputs per Chip | 1 |
| Supplier Package | DSBGA |
| Polarity | Non-Inverting |
| Logic Family | AUC |
| Number of Input Enables per Chip | 0 |
| Logic Function | Buffer/Line Driver |
| Maximum Operating Supply Voltage | 2.7 V |
| Tolerant I/Os | 3.6 V |
| Number of Inputs per Chip | 1 |
| Maximum Propagation Delay Time @ Maximum CL | [email protected]|[email protected] ns |
| Minimum Operating Supply Voltage | 0.8 V |
| Propagation Delay Test Condition | 30 pF |
| Number of Output Enables per Chip | 1 Low |
| Max Processing Temp | 260 |
| Lead Finish | Tin/Silver/Copper |
| Rad Hard | No |
| Bus Hold | No |
| Input Signal Type | Single-Ended |
| Mounting | Surface Mount |
| Number of Channels per Chip | 1 |
| Typical Operating Supply Voltage | 1.8|2.5 V |
| MSL Level | 1 |
| Maximum High Level Output Current | -9 mA |
| Maximum Quiescent Current | 10 uA |
| Maximum Low Level Output Current | 9 mA |
| Fabrication Technology | CMOS |
| Output Type | 3-State |
| Number of Elements per Chip | 1 |
| Pin Count | 5 |
| Package | 5DSBGA |
| Replacement Part Number | PART-SN74AUC1G125YZPR |
| Weight | Contact us |
| Country of Origin | - |
