Please contact us for more photos of SN74LV07ADR
| Part Number | SN74LV07ADR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 480720 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Buffer Driver 6-CH Non-Inverting Open Drain CMOS 14-Pin SOIC T R |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | SN74LV07ADR |
| Datasheet download |  SN74LV07ADR.pdf |
| Part Number | SN74LV07ADR |
|---|---|
| Tolerant I/Os | 5 V |
| Number of Inputs per Chip | 6 |
| Number of Channels per Chip | 6 |
| Output Type | Open Drain |
| Pin Count | 14 |
| Number of Output Enables per Chip | 0 |
| Minimum Operating Supply Voltage | 2 V |
| Number of Outputs per Chip | 6 |
| Product Dimensions | 8.75 x 4 x 1.5 mm |
| Supplier Package | SOIC |
| Typical Operating Supply Voltage | 2.5|3.3|5 V |
| Maximum High Level Output Current | -0.002 mA |
| Maximum Propagation Delay Time @ Maximum CL | [email protected]|[email protected]|7.5@5V ns |
| Maximum Quiescent Current | 20 uA |
| Polarity | Non-Inverting |
| Propagation Delay Test Condition | 50 pF |
| Maximum Operating Supply Voltage | 5.5 V |
| Bus Hold | No |
| Number of Input Enables per Chip | 0 |
| Input Signal Type | Single-Ended |
| Fabrication Technology | CMOS |
| Mounting | Surface Mount |
| Lead Finish | Gold |
| Rad Hard | No |
| Operating Temperature | -40 to 85 °C |
| MSL Level | 1 |
| Max Processing Temp | 260 |
| Logic Function | Buffer/Driver |
| Maximum Low Level Output Current | 16 mA |
| Logic Family | LV |
| Number of Elements per Chip | 6 |
| Package | 14SOIC |
| Replacement Part Number | PART-SN74LV07ADR |
| Weight | Contact us |
| Country of Origin | - |
