Please contact us for more photos of 7802601EA
| Part Number | 7802601EA |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 605360 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Counter Divider Dual 4-Bit Decade UP 16-Pin CDIP Tube |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | 7802601EA |
| Datasheet download |  7802601EA.pdf |
| Part Number | 7802601EA |
|---|---|
| Reset Type | Asynchronous |
| Rad Hard | No |
| Triggering Type | Negative-Edge |
| Type | Decade |
| Operating Temperature | -55 to 125 °C |
| Pin Count | 16 |
| Mounting | Through Hole |
| Number of Elements per Chip | 2 |
| Number of Selection Inputs per Element | 0 |
| Maximum Propagation Delay Time @ Maximum CL | 60@5V ns |
| Supplier Package | CDIP |
| Screening Level | Military |
| Direction Type | Uni-Directional |
| Fabrication Technology | Bipolar |
| Propagation Delay Test Condition | 15 pF |
| Number of Stages | 4 |
| Product Dimensions | 19.56 x 6.92 x 4.57 mm |
| Terminal Count Output | No |
| Parallel Enable Input | No |
| Number of Count Input Enables | 0 |
| Number of Element Inputs | 2 |
| Logic Function | Counter/Divider |
| Typical Operating Supply Voltage | 5 V |
| Logic Family | LS |
| Number of Element Outputs | 4 |
| Operation Mode | UP Counter |
| Maximum Operating Supply Voltage | 5.5 V |
| Minimum Operating Supply Voltage | 4.5 V |
| Package | 16CDIP |
| Replacement Part Number | PART-7802601EA |
| Weight | Contact us |
| Country of Origin | - |
