| Part Number | SN74LV595AQPWRQ1 |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 744770 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Shift Register Single 8-Bit Serial to Serial Parallel 16-Pin TSSOP T R |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | SN74LV595AQPWRQ1 |
| Datasheet download |  SN74LV595AQPWRQ1.pdf |
| Part Number | SN74LV595AQPWRQ1 |
|---|---|
| Tolerant I/Os | 5 V |
| Propagation Delay Test Condition | 50 pF |
| Maximum Propagation Delay Time @ Maximum CL | [email protected]|[email protected]|10.2@5V ns |
| Pin Count | 16 |
| Parallel Enable Input | No |
| Terminal Count Output | No |
| Number of Count Input Enables | 0 |
| Logic Function | Shift Register |
| Output Type | 3-State |
| Number of Selection Inputs per Element | 0 |
| Max Processing Temp | 260 |
| Rad Hard | No |
| Operating Temperature | -40 to 125 °C |
| Lead Finish | Gold |
| Fabrication Technology | CMOS |
| Operation Mode | Serial to Serial/Parallel |
| Typical Operating Supply Voltage | 2.5|3.3|5 V |
| Number of Elements per Chip | 1 |
| Number of Element Inputs | 1 |
| Mounting | Surface Mount |
| Logic Family | LV |
| Supplier Package | TSSOP |
| Direction Type | Uni-Directional |
| Product Dimensions | 5.1 x 4.5 x 1.05 mm |
| Triggering Type | Positive-Edge |
| Minimum Operating Supply Voltage | 2 V |
| Number of Element Outputs | 9 |
| Maximum Operating Supply Voltage | 5.5 V |
| MSL Level | 1 |
| Screening Level | Automotive |
| Number of Stages | 8 |
| Package | 16TSSOP |
| Replacement Part Number | PART-SN74LV595AQPWRQ1 |
| Weight | Contact us |
| Country of Origin | - |
