Please contact us for more photos of TPS40210DRCT
| Part Number | TPS40210DRCT |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 470220 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Current Mode PWM Controller 5V to 260V 400mA 10-Pin VSON EP T R |
| Category | Power Management IC |
| Family | PWM Controllers |
| ROHS Compliant | Yes |
| MSL Level | TPS40210DRCT |
| Datasheet download |  TPS40210DRCT.pdf |
| Part Number | TPS40210DRCT |
|---|---|
| Supplier Package | VSON EP |
| MSL Level | 2 |
| Mounting | Surface Mount |
| Maximum Duty Cycle | 95 % |
| Output Current | 400 mA |
| Pin Count | 10 |
| Adjustable Output | Yes |
| Operating Temperature | -40 to 125 °C |
| Lead Finish | Gold |
| Switching Frequency | 35 to 1000 kHz |
| Max Processing Temp | 260 |
| Number of PWM Outputs | 1 |
| Rad Hard | No |
| Output Voltage | 5 to 260 V |
| On/Off Pin | Yes |
| Product Dimensions | 3.15 x 3.15 x 0.95 mm |
| Package | 10VSON EP |
| Replacement Part Number | PART-TPS40210DRCT |
| Weight | Contact us |
| Country of Origin | - |
