Please contact us for more photos of 74LVC138APW,118
| Part Number | 74LVC138APW,118 |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 340470 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Decoder Demultiplexer Single 3-to-8 16-Pin TSSOP T R |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | 74LVC138APW,118 |
| Datasheet download |  74LVC138APW,118.pdf |
| Part Number | 74LVC138APW,118 |
|---|---|
| Lead Finish | Gold |
| Maximum Quiescent Current | 0.0001 mA |
| Maximum Operating Supply Voltage | 3.6 V |
| Product Dimensions | 5.1 x 4.5 x 0.95 mm |
| Maximum Propagation Delay Time @ Maximum CL | [email protected]|[email protected] ns |
| Logic Function | Decoder/Demultiplexer |
| Number of Element Inputs | 3 |
| Number of Input Enables per Element | 3 |
| Number of Element Outputs | 8 |
| Polarity | Inverting |
| Max Processing Temp | 250|260 |
| Minimum Operating Supply Voltage | 1.2 V |
| Demultiplexing Capability | 1-of-8 |
| Typical Operating Supply Voltage | 1.8|2.5|3.3 V |
| Number of Output Enables per Element | 0 |
| Maximum High Level Output Current | -24 mA |
| Rad Hard | No |
| Mounting | Surface Mount |
| Propagation Delay Test Condition | 50 pF |
| Pin Count | 16 |
| Tolerant I/Os | 5 V |
| Maximum Low Level Output Current | 24 mA |
| Supplier Package | TSSOP |
| Fabrication Technology | CMOS |
| Logic Family | LVC |
| Operating Temperature | -40 to 125 °C |
| Number of Elements per Chip | 1 |
| MSL Level | 1 |
| Package | 16TSSOP |
| Replacement Part Number | PART-74LVC138APW,118 |
| Weight | Contact us |
| Country of Origin | - |
