Please contact us for more photos of KW-5R5C224-R
| Part Number | KW-5R5C224-R |
|---|---|
| Manufacturer | Eaton |
| Quantity in stock | 366000 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap 0.22F 5.5V -20% to 80% 1000 hr (13.5 X 8.3mm) Radial Stacked Coin 5mm 50 Ohm 85\u00b0C Bulk |
| Category | Capacitors |
| Family | Capacitor Electric Double Layer |
| ROHS Compliant | Yes |
| MSL Level | KW-5R5C224-R |
| Datasheet download |  KW-5R5C224-R.pdf |
| Part Number | KW-5R5C224-R |
|---|---|
| Package/Case | 13.5(Max) X 8.3(Max) |
| Tolerance | -20 to 80 % |
| Voltage(DC) | 5.5 V |
| Mounting | Through Hole |
| Termination Style | Radial |
| Lead Pitch For Radial | 5 mm |
| Rad Hard | No |
| Lead Diameter | 0.8 mm |
| Capacitance Value | 0.22 F |
| Construction | Stacked Coin |
| Equivalent Series Resistance | 50 Ohm |
| Product Dimensions | 8.3 mm |
| Operating Temperature | -40 to 85 °C |
| Product Diameter | 13.5(Max) mm |
| Product Height | 8.3(Max) mm |
| Product Weight | 3.7 gram |
| Replacement Part Number | PART-KW-5R5C224-R |
| Weight | Contact us |
| Country of Origin | - |
| Image | Part Number and Brand | Brief Description and PDF Datasheet |
|---|---|---|
|
Nichicon | Cap 1F 2.7V 20% 1000 hr (6.3 X 9mm) Radial 2.5mm Bulk Download PDF datasheet for JUWT1105MCD.pdf |
|
AVX | Cap 47000uF 2.5V -20% to 80% (20 X 15 X 4mm) Planar Mount 0.1 Ohm 70\u00b0C Bulk Download PDF datasheet for BZ054B473ZSBCS.pdf |
|
Panasonic | Cap 0.47F 5.5V -20% to 150% 1000 hr (20 X 19 X 6mm) Radial Stacked Coin 20mm 70\u00b0C Tray Download PDF datasheet for EECS5R5H474.pdf |
|
KEMET | Cap 0.47F 3.5V -20% to 80% (10.5 X 8.5mm) SMD Cylindrical 70\u00b0C Embossed T R Download PDF datasheet for FC0V474ZFTBR24.pdf |
|
Panasonic | Cap 0.47F 5.5V -20% to 80% 1000 hr (21.5 X 9.5mm) Radial Stacked Coin 5mm 85\u00b0C Tray Download PDF datasheet for EECF5R5H474N.pdf |
|
KEMET | Cap 47000uF 5.5V -20% to 80% (10.5 X 5.5mm) SMD Cylindrical 70\u00b0C Embossed T R Download PDF datasheet for FC0H473ZFTBR24.pdf |
|
Panasonic | Cap 0.22F 5.5V -20% to 80% 1000 hr (11.5 X 10.5 X 6mm) Radial Stacked Coin 10mm 70\u00b0C Bulk Download PDF datasheet for EECS0HD224H.pdf |
|
Eaton | Cap 1.5F 5.4V -10% to 30% 1000 hr (17.3 X 9 X 22mm) Radial 11.8mm 0.16 Ohm 65\u00b0C Bulk Download PDF datasheet for PHV-5R4V155-R.pdf |
|
Panasonic | Cap 1F 3.6V -20% to 80% 2000 hr (20.5 X 19 X 6.5mm) Radial Stacked Coin 20mm 85\u00b0C Tray Download PDF datasheet for EECRG0V105HN.pdf |
|
AVX | Cap 15000uF 4.5V -20 to 80% 1000hr (17 X 15 X 2.3mm) Solder Flat 70\u00b0C Bulk Download PDF datasheet for BZ094B153ZWB.pdf |
