Please contact us for more photos of DSP1-DC24V-F
| Part Number | DSP1-DC24V-F |
|---|---|
| Manufacturer | Panasonic |
| Quantity in stock | 632930 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Electromechanical Relay SPST-NO SPST-NC 5A 24VDC 1.92KOhm Through Hole |
| Category | Switches and Relays |
| Family | Relays |
| ROHS Compliant | Yes |
| MSL Level | DSP1-DC24V-F |
| Datasheet download |  DSP1-DC24V-F.pdf |
| Part Number | DSP1-DC24V-F |
|---|---|
| AC Coil Voltage | |
| Maximum Power Rating | |
| Type | |
| DC Coil Voltage | |
| Maximum Current Rating | |
| Coil Current | |
| Rad Hard | No |
| Maximum DC Voltage Rating | |
| Maximum AC Voltage Rating | |
| Maximum Pick-Up Voltage | |
| Contact Arrangement | SPST-NO|SPST-NC |
| Max Processing Temp | 250 |
| Operate Time | 10 ms |
| Contact Material | Silver Tin Oxide/Gold Flash |
| Coil Resistance | 1.92 kOhm |
| Minimum Dropout Voltage | 2.4 Vdc |
| Relay Construction | Non-Latching |
| Mounting | Through Hole |
| Supplier Package | DIP |
| Product Dimensions | 20.2 x 11 x 10.5 mm |
| Operating Temperature | -40 to 65 °C |
| Product Depth | 11 mm |
| Product Height | 10.5 mm |
| Product Length | 20.2 mm |
| Replacement Part Number | PART-DSP1-DC24V-F |
| Weight | Contact us |
| Country of Origin | - |
