Part Number | SN74AHC02PWR |
---|---|
Manufacturer | Texas Instruments |
Quantity in stock | 392820 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | NOR Gate 4-Element 2-IN CMOS 14-Pin TSSOP T R |
Category | Logic & Timing IC |
Family | Logic ICs |
ROHS Compliant | Yes |
MSL Level | SN74AHC02PWR |
Datasheet download | ![]() |
Part Number | SN74AHC02PWR |
---|---|
Logic Function | NOR |
Fabrication Technology | CMOS |
Minimum Operating Supply Voltage | 2 V |
Operating Temperature | -40 to 85 °C |
Maximum Quiescent Current | 2 uA |
Number of Selection Inputs per Element | 0 |
Max Processing Temp | 260 |
Maximum Propagation Delay Time @ Maximum CL | [email protected]|7.5@5V ns |
Supplier Package | TSSOP |
Rad Hard | No |
MSL Level | 1 |
Mounting | Surface Mount |
Pin Count | 14 |
Maximum Operating Supply Voltage | 5.5 V |
Product Dimensions | 5.1 x 4.5 x 1.05 mm |
Number of Output Enables per Element | 0 |
Lead Finish | Gold |
Package | 14TSSOP |
Replacement Part Number | PART-SN74AHC02PWR |
Weight | Contact us |
Country of Origin | - |
