| Part Number | PBSS4220PANSX |
|---|---|
| Manufacturer | NXP |
| Quantity in stock | 142170 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans GP BJT NPN PNP 20V 2A 6-Pin SOT-1118D T R |
| Category | Discrete Semiconductor |
| Family | Bipolar Transistor |
| ROHS Compliant | Yes |
| MSL Level | PBSS4220PANSX |
| Datasheet download |  PBSS4220PANSX.pdf |
| Part Number | PBSS4220PANSX |
|---|---|
| Maximum DC Collector Current | 2 A |
| Minimum DC Current Gain | 250@100mA@2V|230@500mA@2V|200@1A@2V|150@2A|2V |
| Screening Level | Automotive |
| Maximum Base Emitter Saturation Voltage | 1@[email protected]|1.1@50mA@1A|1.3@200mA@2A V |
| Type | NPN|PNP |
| Operating Temperature | -55 to 150 °C |
| Maximum Collector Base Voltage | 20 V |
| Package Dimensions | 2 x 2 x 0.58 mm |
| Maximum Collector Emitter Voltage | 20 V |
| Maximum Transition Frequency | 120 MHz |
| Rad Hard | No |
| Mounting | Surface Mount |
| Supplier Package | SOT-1118D |
| Lead Finish | Tin |
| Maximum Collector Emitter Saturation Voltage | 0.09@[email protected]|0.17@50mA@1A|0.32@200mA@2A V |
| Pin Count | 6 |
| Maximum Emitter Base Voltage | 7 V |
| Maximum Power Dissipation | 960 mW |
| Moisture Sensitivity Level | 1 |
| Package | 6SOT-1118D |
| Replacement Part Number | PART-PBSS4220PANSX |
| Weight | Contact us |
| Country of Origin | - |
