Please contact us for more photos of PHPT60603PYX
| Part Number | PHPT60603PYX |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 745610 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans GP PNP 60V 3A 4-Pin SOT-669 T R |
| Category | Discrete Semiconductor |
| Family | Bipolar Transistor |
| ROHS Compliant | Yes |
| MSL Level | PHPT60603PYX |
| Datasheet download |  PHPT60603PYX.pdf |
| Part Number | PHPT60603PYX |
|---|---|
| Maximum DC Collector Current | 3 A |
| Maximum Collector Base Voltage | 60 V |
| Product Dimensions | 5(Max) x 4.1(Max) x 1.1(Max) |
| Screening Level | Automotive |
| Pin Count | 4 |
| Minimum DC Current Gain | 150@500mA@2V|150@1A@2V|80@2A@2V|35@3A@2V |
| Maximum Transition Frequency | 110 MHz |
| Supplier Package | SOT-669 |
| Maximum Collector Emitter Voltage | 60 V |
| Rad Hard | No |
| Mounting | Surface Mount |
| Maximum Power Dissipation | 25000 mW |
| Max Processing Temp | 260 |
| Maximum Base Emitter Saturation Voltage | 1@50mA@1A|1.2@200mA@2A V |
| Maximum Emitter Base Voltage | 8 V |
| Maximum Collector Emitter Saturation Voltage | 0.225@50mA@1A|0.36@300mA@3A V |
| Lead Finish | Tin |
| Operating Temperature | -55 to 175 °C |
| Type | PNP |
| MSL Level | 1 |
| Package | 4SOT-669 |
| Replacement Part Number | PART-PHPT60603PYX |
| Weight | Contact us |
| Country of Origin | - |
