| Part Number | PMBT3904 DG,215 |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 191650 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Trans GP BJT NPN 40V 0.2A 3-Pin TO-236AB T R |
| Category | Discrete Semiconductor |
| Family | Bipolar Transistor |
| ROHS Compliant | Yes |
| MSL Level | PMBT3904 DG,215 |
| Datasheet download |  PMBT3904 DG,215.pdf |
| Part Number | PMBT3904 DG,215 |
|---|---|
| Rad Hard | No |
| Pin Count | 3 |
| Mounting | Surface Mount |
| Maximum Base Emitter Saturation Voltage | 0.85@1mA@10mA|0.95@5mA@50mA V |
| Maximum Collector Emitter Saturation Voltage | 0.2@1mA@10mA|0.3@5mA@50mA V |
| Minimum DC Current Gain | [email protected]@1V|80@1mA@1V|100@10mA@1V|60@50mA@1V|30@100mA@1V |
| Product Dimensions | 3 x 1.4 x 1 mm |
| MSL Level | 1 |
| Type | NPN |
| Operating Temperature | -65 to 150 °C |
| Supplier Package | TO-236AB |
| Maximum Power Dissipation | 250 mW |
| Max Processing Temp | 260 |
| Maximum Collector Base Voltage | 60 V |
| Maximum Collector Emitter Voltage | 40 V |
| Maximum DC Collector Current | 0.2 A |
| Maximum Emitter Base Voltage | 6 V |
| Package | 3TO-236AB |
| Replacement Part Number | PART-PMBT3904 DG,215 |
| Weight | Contact us |
| Country of Origin | - |
