| Part Number | AH1809-W-7 |
|---|---|
| Manufacturer | Diodes Incorporated |
| Quantity in stock | 285110 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Hall Effect Sensor 2.5mA Omnipolar 2.5V to 5.5V 3-Pin SC-59 T R |
| Category | Sensors & Transducers |
| Family | Magnetic Sensors |
| ROHS Compliant | Yes |
| MSL Level | AH1809-W-7 |
| Datasheet download |  AH1809-W-7.pdf |
| Part Number | AH1809-W-7 |
|---|---|
| Mounting | Surface Mount |
| Supplier Package | SC-59 |
| MSL Level | 1 |
| Module/IC Classification | IC |
| Pin Count | 3 |
| Magnetic Type | Omnipolar |
| Operating Supply Voltage | 2.5 to 5.5 V |
| Minimum Release Point | 90 Gs |
| Product Dimensions | 3 x 1.6 x 1.1 |
| Maximum Supply Current | 6 mA |
| Output Current | 2.5 mA |
| Maximum Operating Point | 165 Gs |
| Max Processing Temp | 260 |
| Screening Level | Extended Industrial |
| Operating Temperature | -40 to 125 °C |
| Rad Hard | No |
| Package | 3SC-59 |
| Replacement Part Number | PART-AH1809-W-7 |
| Weight | Contact us |
| Country of Origin | - |
