Please contact us for more photos of M20-9771246
| Part Number | M20-9771246 |
|---|---|
| Manufacturer | Harwin |
| Quantity in stock | 810350 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | 2.54mm (0.1\") Pitch SIL Vertical PC Tail Pin Header, 5.8mm mating pin height, tin, 12 contacts |
| Category | Connectors |
| Family | Connector Headers and PCB Receptacles |
| ROHS Compliant | Yes |
| MSL Level | M20-9771246 |
| Datasheet download |  M20-9771246.pdf |
| Part Number | M20-9771246 |
|---|---|
| Mounting | PC Tail / Throughboard |
| Product Dimensions | 30.48 x 2.54 x 8.34 |
| Housing Material | Polyamide (Nylon) 6T |
| Termination Method | Solder |
| Lead Finish | 100% Tin over Nickel |
| Gender | HDR |
| Type | 2.54 (0.1") Pitch Coercial/Industrial Connector mm |
| Number of Contacts | 12 |
| Housing Color | Black |
| Contact Material | Brass |
| Contact Plating | 100% Tin over Nickel |
| Body Orientation | Vertical |
| Operating Temperature | -40 to +105 °C |
| Pitch | 2.54 mm |
| Rad Hard | No |
| Color | Black |
| Max Processing Temp | 260 |
| Pin Count | 12 |
| Product Depth | 2.54 mm |
| Product Height | 8.34 mm |
| Product Length | 30.48 mm |
| Replacement Part Number | PART-M20-9771246 |
| Weight | Contact us |
| Country of Origin | - |
