Please contact us for more photos of EPA1271A-LF
| Part Number | EPA1271A-LF |
|---|---|
| Manufacturer | HPC |
| Quantity in stock | 692150 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Telecom Transformer 1:1 2000Vrms 1Ohm Prim. DCR Thru-Hole |
| Category | Transformer |
| Family | Telecom Transformer |
| ROHS Compliant | Yes |
| MSL Level | EPA1271A-LF |
| Datasheet download |  EPA1271A-LF.pdf |
| Part Number | EPA1271A-LF |
|---|---|
| Mounting | Through Hole |
| Transformer Type | Isolation Transformer |
| Lead Finish | Tin |
| Package Type | DIP |
| Rad Hard | No |
| Maximum OCL Inductance | 2.5 mH |
| Maximum DCR Secondary Side | 1 Ohm |
| Pin Count | 16 |
| Supplier Package | DIP |
| Minimum Crosstalk | -70@1MHz dB |
| Maximum Primary Leakage Inductance | 8 uH |
| Maximum Isolation Voltage | 2000 Vrms |
| Max Processing Temp | 260 |
| Turns Ratio | 1:1 |
| Product Dimensions | 22.86 x 11.43(Max) x 10.16(Max) |
| Maximum Interwinding Capacitance | 25 pF |
| Maximum DCR Primary Side | 1 Ohm |
| Lead Style | PC Pin |
| Product Depth | 11.43(Max) mm |
| Product Height | 10.16(Max) mm |
| Product Length | 22.86 mm |
| Replacement Part Number | PART-EPA1271A-LF |
| Weight | Contact us |
| Country of Origin | - |
