Please contact us for more photos of AUIPS7221RTRL
| Part Number | AUIPS7221RTRL |
|---|---|
| Manufacturer | Infineon |
| Quantity in stock | 363430 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Power Switch Hi Side 0.01A 5-Pin(4+Tab) DPAK T R |
| Category | Power Management IC |
| Family | Power Switch |
| ROHS Compliant | Yes |
| MSL Level | AUIPS7221RTRL |
| Datasheet download |  AUIPS7221RTRL.pdf |
| Part Number | AUIPS7221RTRL |
|---|---|
| Switch On Resistance | 0.03 Ohm |
| Maximum Power Dissipation | 2500 mW |
| Product Dimensions | 6.73 x 6.22 x 2.39 mm |
| Operating Temperature | -40 to 150 °C |
| Operating Supply Voltage Range | 6 to 60 V |
| Rad Hard | No |
| Number of Outputs | 1 |
| Max Processing Temp | 260|300 |
| Type | High Side |
| Input Voltage | -0.3 to 5.5 V |
| Mounting | Surface Mount |
| Supplier Package | DPAK |
| MSL Level | 1 |
| Minimum Output Current | 0.01 A |
| Pin Count | 5 |
| Lead Finish | Matte Tin |
| Supply Current | 4 mA |
| Package | 5DPAK |
| Replacement Part Number | PART-AUIPS7221RTRL |
| Weight | Contact us |
| Country of Origin | - |
