Part Number | TCA 3727 G |
---|---|
Manufacturer | Infineon |
Quantity in stock | 490190 Pieces |
Market Price | - |
Our Better Price | Send by email: [email protected] |
Delivery Time | 1 day (can ship today) |
Description | 2-Phase Stepping Motor Driver 24-Pin DSO |
Category | Power Management IC |
Family | Motion Motor Control |
ROHS Compliant | Yes |
MSL Level | TCA 3727 G |
Datasheet download | ![]() |
Part Number | TCA 3727 G |
---|---|
Max Processing Temp | 260 |
Operating Temperature | N/A to 150 °C |
Supplier Package | DSO |
Product Dimensions | 15.6 x 7.6 x 2.45 mm |
Maximum Operating Current | 20 mA |
Pin Count | 24 |
Mounting | Surface Mount |
MSL Level | 1 |
Lead Finish | Matte Tin |
Type | 2-Phase Stepping Motor Driver |
Package | 24DSO |
Replacement Part Number | PART-TCA 3727 G |
Weight | Contact us |
Country of Origin | - |
