Please contact us for more photos of ICL7650SCPA-1Z
| Part Number | ICL7650SCPA-1Z |
|---|---|
| Manufacturer | Intersil |
| Quantity in stock | 766190 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | SP Amp Chopper Stabilization Single \u00b18V 16V 8-Pin PDIP |
| Category | Amplifiers IC |
| Family | SP Amplifier |
| ROHS Compliant | Yes |
| MSL Level | ICL7650SCPA-1Z |
| Datasheet download |  ICL7650SCPA-1Z.pdf |
| Part Number | ICL7650SCPA-1Z |
|---|---|
| Minimum PSRR | 120 dB |
| Supplier Package | PDIP |
| Maximum Input Bias Current | 0.00001@±5V uA |
| Typical Gain Bandwidth Product | 2 MHz |
| Rad Hard | No |
| Operating Temperature | 0 to 70 °C |
| Maximum Dual Supply Voltage | ±8 V |
| Maximum Single Supply Voltage | 16 V |
| Rail to Rail | No |
| Maximum Supply Current | 3@±5V mA |
| Type | Chopper Stabilization |
| Lead Finish | Matte Tin |
| Power Supply Type | Single|Dual |
| Number of Channels per Chip | 1 |
| Screening Level | Commercial |
| Minimum CMRR | 120 dB |
| Minimum Single Supply Voltage | 4.5 V |
| Product Dimensions | 10.16 x 7.11 x 4.95 mm |
| Pin Count | 8 |
| Mounting | Through Hole |
| Minimum Dual Supply Voltage | ±2.25 V |
| Package | 8PDIP |
| Replacement Part Number | PART-ICL7650SCPA-1Z |
| Weight | Contact us |
| Country of Origin | - |
