Please contact us for more photos of INA111AUE4
| Part Number | INA111AUE4 |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 630740 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | SP Amp INSTR Amp Single \u00b118V 16-Pin SOIC Tube |
| Category | Amplifiers IC |
| Family | SP Amplifier |
| ROHS Compliant | Yes |
| MSL Level | INA111AUE4 |
| Datasheet download |  INA111AUE4.pdf |
| Part Number | INA111AUE4 |
|---|---|
| Pin Count | 16 |
| Operating Temperature | -40 to 85 °C |
| Lead Finish | Gold |
| Rad Hard | No |
| Max Processing Temp | 260 |
| MSL Level | 3 |
| Power Supply Type | Dual |
| Maximum Dual Supply Voltage | ±18 V |
| Mounting | Surface Mount |
| Maximum Voltage Gain | 80 dB |
| Number of Channels per Chip | 1 |
| Minimum Dual Supply Voltage | ±6 V |
| Maximum Input Bias Current | 0.00002@±15V uA |
| Rail to Rail | No |
| Product Dimensions | 10.28 x 7.52 x 2.35 mm |
| Supplier Package | SOIC |
| Minimum CMRR | 75 dB |
| Maximum Supply Current | 4.5@±15V mA |
| Type | Instrumentation Amplifier |
| Package | 16SOIC |
| Replacement Part Number | PART-INA111AUE4 |
| Weight | Contact us |
| Country of Origin | - |
