Please contact us for more photos of INA250A4PW
| Part Number | INA250A4PW |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 847470 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | SP Amp Current Sense Amp Single 36V 16-Pin TSSOP Tube |
| Category | Amplifiers IC |
| Family | SP Amplifier |
| ROHS Compliant | Yes |
| MSL Level | INA250A4PW |
| Datasheet download |  INA250A4PW.pdf |
| Part Number | INA250A4PW |
|---|---|
| Package Dimensions | 5 x 4.4 x 1.05 mm |
| Pin Count | 16 |
| Minimum Single Supply Voltage | 2.7 V |
| Supplier Package | TSSOP |
| Maximum Supply Current | 0.3@5V mA |
| Lead Finish | Gold Over Nickel Palladium |
| Minimum CMRR | 108 dB |
| Maximum Input Bias Current | ±35@5V uA |
| Moisture Sensitivity Level | 2 |
| Maximum Processing Temperature | 260 °C |
| Typical Gain Bandwidth Product | 0.011 MHz |
| Number of Channels per Chip | 1 |
| Rail to Rail | No |
| Operating Temperature | -40 to 125 °C |
| Mounting | Surface Mount |
| Rad Hard | No |
| Screening Level | Extended Industrial |
| Type | Current Sense Amplifier |
| Power Supply Type | Single |
| Maximum Single Supply Voltage | 36 V |
| Package | 16TSSOP |
| Replacement Part Number | PART-INA250A4PW |
| Weight | Contact us |
| Country of Origin | - |
