| Part Number | 74LV04PW118 |
|---|---|
| Manufacturer | Nexperia |
| Quantity in stock | 771320 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Inverter 6-Element CMOS 14-Pin TSSOP T R |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | 74LV04PW118 |
| Datasheet download |  74LV04PW118.pdf |
| Part Number | 74LV04PW118 |
|---|---|
| Maximum Quiescent Current | 40 uA |
| Lead Finish | Gold |
| Product Dimensions | 5.1 x 4.5 x 0.95 mm |
| Number of Elements per Chip | 6 |
| Maximum High Level Output Current | -12 mA |
| Minimum Operating Supply Voltage | 1 V |
| Pin Count | 14 |
| Logic Family | LV |
| Typical Operating Supply Voltage | 3.3 V |
| Rad Hard | No |
| Mounting | Surface Mount |
| Logic Function | Inverter |
| Maximum Propagation Delay Time @ Maximum CL | [email protected]|14@2V|[email protected]|[email protected] ns |
| Propagation Delay Test Condition | 50 pF |
| Maximum Low Level Output Current | 12 mA |
| MSL Level | 1 |
| Maximum Operating Supply Voltage | 5.5 V |
| Supplier Package | TSSOP |
| Fabrication Technology | CMOS |
| Operating Temperature | -40 to 125 °C |
| Max Processing Temp | 260 |
| Package | 14TSSOP |
| Replacement Part Number | PART-74LV04PW118 |
| Weight | Contact us |
| Country of Origin | - |
