Please contact us for more photos of SN74LVC3GU04DCUR
| Part Number | SN74LVC3GU04DCUR |
|---|---|
| Manufacturer | Texas Instruments |
| Quantity in stock | 878250 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Inverter 3-Element CMOS 8-Pin VSSOP T R |
| Category | Logic & Timing IC |
| Family | Logic ICs |
| ROHS Compliant | Yes |
| MSL Level | SN74LVC3GU04DCUR |
| Datasheet download |  SN74LVC3GU04DCUR.pdf |
| Part Number | SN74LVC3GU04DCUR |
|---|---|
| Number of Elements per Chip | 3 |
| Rad Hard | No |
| Logic Family | LVC |
| Typical Operating Supply Voltage | 1.8|2.5|3.3|5 V |
| Maximum Quiescent Current | 10 uA |
| Maximum Operating Supply Voltage | 5.5 V |
| Minimum Operating Supply Voltage | 1.65 V |
| Fabrication Technology | CMOS |
| Maximum Propagation Delay Time @ Maximum CL | [email protected]|3.2@5V ns |
| Product Dimensions | 2.3 x 2 x 0.85 mm |
| Maximum High Level Output Current | -32 mA |
| Supplier Package | VSSOP |
| Maximum Low Level Output Current | 32 mA |
| Logic Function | Inverter |
| MSL Level | 1 |
| Operating Temperature | -40 to 85 °C |
| Max Processing Temp | 260 |
| Propagation Delay Test Condition | 50 pF |
| Screening Level | Commercial |
| Pin Count | 8 |
| Lead Finish | Gold |
| Mounting | Surface Mount |
| Package | 8VSSOP |
| Replacement Part Number | PART-SN74LVC3GU04DCUR |
| Weight | Contact us |
| Country of Origin | - |
