Please contact us for more photos of C0805C120D1GAC7800
| Part Number | C0805C120D1GAC7800 |
|---|---|
| Manufacturer | KEMET |
| Quantity in stock | 271740 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Ceramic 12pF 100V C0G 0.5pF SMD 0805 125\u00b0C Paper T R |
| Category | Capacitors |
| Family | Capacitor Ceramic Multilayer |
| ROHS Compliant | Yes |
| MSL Level | C0805C120D1GAC7800 |
| Datasheet download |  C0805C120D1GAC7800.pdf |
| Part Number | C0805C120D1GAC7800 |
|---|---|
| Construction | Flat |
| Lead Finish | Matte Tin |
| Dielectric | C0G |
| Case Style | Ceramic Chip |
| Operating Temperature | -55 to 125 °C |
| Mounting | Surface Mount |
| Capacitance Value | 12 pF |
| Case Size | 0805 |
| Product Dimensions | 2 x 1.25 x 0.78 mm |
| MSL Level | 1 |
| Voltage(DC) | 100 V |
| Tolerance | 0.5 pF |
| Rad Hard | No |
| Max Processing Temp | 260 |
| Package/Case | 0805 |
| Product Depth | 1.25 mm |
| Product Height | 0.78 mm |
| Product Length | 2 mm |
| Replacement Part Number | PART-C0805C120D1GAC7800 |
| Weight | Contact us |
| Country of Origin | - |
