Please contact us for more photos of PHE426HR8100JR06L2
| Part Number | PHE426HR8100JR06L2 |
|---|---|
| Manufacturer | KEMET |
| Quantity in stock | 584640 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Cap Film 10uF 250V PP 5% (41 X 16.5 X 32mm) Radial 37.5mm 105\u00b0C Tray |
| Category | Capacitors |
| Family | Capacitor Film |
| ROHS Compliant | Yes |
| MSL Level | PHE426HR8100JR06L2 |
| Datasheet download |  PHE426HR8100JR06L2.pdf |
| Part Number | PHE426HR8100JR06L2 |
|---|---|
| Voltage(AC) | 160 V |
| Tolerance | 5 % |
| Product Dimensions | 41 x 16.5 x 32 mm |
| Termination Style | Radial |
| Package/Case | 41(Max) X 16.5(Max) X 32(Max) |
| Dielectric Material | |
| Voltage(DC) | 250 V |
| Lead Pitch For Radial | 37.5 mm |
| Rad Hard | No |
| Capacitance Value | 10 uF |
| Seated Plane Height | 32 mm |
| Operating Temperature | -55 to 105 °C |
| Dielectric | PP |
| Mounting | Through Hole |
| Lead Finish | Tin |
| Product Depth | 16.5(Max) mm |
| Product Height | 32(Max) mm |
| Product Length | 41(Max) mm |
| Replacement Part Number | PART-PHE426HR8100JR06L2 |
| Weight | Contact us |
| Country of Origin | - |
