Please contact us for more photos of HZ1206E601R-10
| Part Number | HZ1206E601R-10 |
|---|---|
| Manufacturer | Laird |
| Quantity in stock | 129350 Pieces |
| Market Price | - |
| Our Better Price | Send by email: [email protected] |
| Delivery Time | 1 day (can ship today) |
| Description | Ind Chip Bead 600Ohm 100MHz Ferrite 500mA 1206 T R |
| Category | Inductor |
| Family | Inductor Surface Mount |
| ROHS Compliant | Yes |
| MSL Level | HZ1206E601R-10 |
| Datasheet download |  HZ1206E601R-10.pdf |
| Part Number | HZ1206E601R-10 |
|---|---|
| Type | Chip Bead |
| Core Material | Ferrite |
| Product Dimensions | 3.2 x 1.6 x 1.1 mm |
| Max Processing Temp | 250 |
| Package/Case | 1206 |
| Lead Finish | Tin |
| Operating Temperature | -55 to 125 °C |
| Test Frequency | 100 MHz |
| Product Depth | 1.6 mm |
| Product Height | 1.1 mm |
| Product Length | 3.2 mm |
| Replacement Part Number | PART-HZ1206E601R-10 |
| Weight | Contact us |
| Country of Origin | - |
